spring 创建bean的过程以及循环依赖的解决方案

  1. 准备Bean容器 prepareApplicationContext() (重要!!)

    1. 设置环境 environment到context容器中,添加各种listener等

    2. refreshContext(重要)

      在这一步中,刷新整个context,此操作将注册所有bean到BeanFactory中,启动spring boot 中的webserver等

      详细的refresh操作如下

      @Override
      public void refresh() throws BeansException, IllegalStateException {
         // 上锁
         synchronized (this.startupShutdownMonitor) {

            // 准备工作,记录下容器的启动时间、标记“已启动”状态、处理配置文件中的占位符
           prepareRefresh();

            // 这步比较关键,这步完成后,配置文件就会解析成一个个 Bean 定义,注册到 BeanFactory 中,
            // 当然,这里说的 Bean 还没有初始化,只是配置信息都提取出来了,
            // 注册也只是将这些信息都保存到了注册中心(说到底核心是一个 beanName-> beanDefinition 的 map)
            ConfigurableListableBeanFactory beanFactory = obtainFreshBeanFactory();

            // 设置 BeanFactory 的类加载器,添加几个 BeanPostProcessor,手动注册几个特殊的 bean
            // 这块待会会展开说
            prepareBeanFactory(beanFactory);

            try {
               // 【这里需要知道 BeanFactoryPostProcessor 这个知识点,Bean 如果实现了此接口,
               // 那么在容器初始化以后,Spring 会负责调用里面的 postProcessBeanFactory 方法。】

               // 这里是提供给子类的扩展点,到这里的时候,所有的 Bean 都加载、注册完成了,但是都还没有初始化
               // 具体的子类可以在这步的时候添加一些特殊的 BeanFactoryPostProcessor 的实现类或做点什么事
               postProcessBeanFactory(beanFactory);
               // 调用 BeanFactoryPostProcessor 各个实现类的 postProcessBeanFactory(factory) 方法
               invokeBeanFactoryPostProcessors(beanFactory);

               // 注册 BeanPostProcessor 的实现类,注意看和 BeanFactoryPostProcessor 的区别
               // 此接口两个方法: postProcessBeforeInitialization 和 postProcessAfterInitialization
               // 两个方法分别在 Bean 初始化之前和初始化之后得到执行。注意,到这里 Bean 还没初始化
               registerBeanPostProcessors(beanFactory);

               // 初始化当前 ApplicationContext 的 MessageSource,国际化不是重点,不展开
               initMessageSource();

               // 初始化当前 ApplicationContext 的事件广播器,这里也不展开了
               initApplicationEventMulticaster();

               // 从方法名就可以知道,典型的模板方法(钩子方法),
               // 具体的子类可以在这里初始化一些特殊的 Bean(在初始化 singleton beans 之前)
               onRefresh();

               // 注册事件监听器,监听器需要实现 ApplicationListener 接口。这也不是我们的重点,过
               registerListeners();

               // 重点,重点,重点
               // 初始化所有的 singleton beans
               //(lazy-init 的除外)
               finishBeanFactoryInitialization(beanFactory);

               // 最后,广播事件,ApplicationContext 初始化完成
               finishRefresh();
            }

            catch (BeansException ex) {
               if (logger.isWarnEnabled()) {
                  logger.warn("Exception encountered during context initialization - " +
                        "cancelling refresh attempt: " + ex);
               }

               // Destroy already created singletons to avoid dangling resources.
               // 销毁已经初始化的 singleton 的 Beans,以免有些 bean 会一直占用资源
               destroyBeans();
               // Reset 'active' flag.
               cancelRefresh(ex);
               throw ex;
            }

            finally {
               // Reset common introspection caches in Spring's core, since we
               // might not ever need metadata for singleton beans anymore...
               resetCommonCaches();
            }
         }
      }

      spring中要求context的refresh操作必须是线程安全的,所以使用了startupShutdownMonitor为代码块上锁,同时使用到该锁的还有close()方法,让refresh和close不能同时进行


spring bean 存储和获取过程

我们知道,spring在启动过程中会有依赖注入这一特性,即标记了@Autowired的成员变量会被spring进行递归注册bean,下面介绍他们的实现,首先打出递归调用栈

这张图表明了spring在获取一个bean的时候,如果没有,会先去创建一个bean,在创建的过程中会去创建所有被引用的且未被创建的bean,最终又会调用getBean方法进行递归,下面会逐个介绍所有方法

spring获取过程 doGetBean()

spring bean的获取主要是通过BeanFactory做到的,在获取bean的过程中,spring实现了依赖注入这样的核心功能。一下为源码

源代码在org.springframework.beans.factory.support.AbstractBeanFactory#doGetBean中

   /**
        * Return an instance, which may be shared or independent, of the specified bean.
        * @param name the name of the bean to retrieve
        * @param requiredType the required type of the bean to retrieve
        * @param args arguments to use when creating a bean instance using explicit arguments
        * (only applied when creating a new instance as opposed to retrieving an existing one)
        * @param typeCheckOnly whether the instance is obtained for a type check,
        * not for actual use
        * @return an instance of the bean
        * @throws BeansException if the bean could not be created
        */
       protected <T> T doGetBean(final String name, @Nullable final Class<T> requiredType,
               @Nullable final Object[] args, boolean typeCheckOnly) throws BeansException {


           //拿到bean的名称
           final String beanName = transformedBeanName(name);
           Object bean;

           //检查是否是singleton 的作用域,总所周知,spring拥有singleton、prototype、session等作用域,以下方法是查找单例singleton作用域的
           Object sharedInstance = getSingleton(beanName);
           if (sharedInstance != null && args == null) {
               if (logger.isDebugEnabled()) {
                   if (isSingletonCurrentlyInCreation(beanName)) {
                       logger.debug("Returning eagerly cached instance of singleton bean '" + beanName +
                               "' that is not fully initialized yet - a consequence of a circular reference");
                   }
                   else {
                       logger.debug("Returning cached instance of singleton bean '" + beanName + "'");
                   }
               }
               bean = getObjectForBeanInstance(sharedInstance, name, beanName, null);
           }

           else {
               // Fail if we're already creating this bean instance:
               // We're assumably within a circular reference.

               //创建过了此 beanName 的 prototype 类型的 bean,那么抛异常

               if (isPrototypeCurrentlyInCreation(beanName)) {
                   throw new BeanCurrentlyInCreationException(beanName);
               }

               // Check if bean definition exists in this factory.
               // 检查下这个BeanDefinition是否存在
               BeanFactory parentBeanFactory = getParentBeanFactory();
               // 如果当前没有且parent不为空,就去parent里去找
               if (parentBeanFactory != null && !containsBeanDefinition(beanName)) {
                   // Not found -> check parent.
                   String nameToLookup = originalBeanName(name);
                   if (parentBeanFactory instanceof AbstractBeanFactory) {
                       return ((AbstractBeanFactory) parentBeanFactory).doGetBean(
                               nameToLookup, requiredType, args, typeCheckOnly);
                   }
                   else if (args != null) {
                       // Delegation to parent with explicit args.
                       return (T) parentBeanFactory.getBean(nameToLookup, args);
                   }
                   else {
                       // No args -> delegate to standard getBean method.
                       return parentBeanFactory.getBean(nameToLookup, requiredType);
                   }
               }

               if (!typeCheckOnly) {
                   markBeanAsCreated(beanName);
               }

               try {
                   final RootBeanDefinition mbd = getMergedLocalBeanDefinition(beanName);
                   checkMergedBeanDefinition(mbd, beanName, args);

                   // Guarantee initialization of beans that the current bean depends on.
                   //找到depends-on类型的引用 depends-on 的循环引用要求明确使用@DependsOn注解 表明当实例化一个bean时,spring保证该Bean所依赖的其他bean已经初始化
                   String[] dependsOn = mbd.getDependsOn();
                   if (dependsOn != null) {
                       for (String dep : dependsOn) {
                           /// 这里指的是通过 depends-on 定义造成的循环依赖,注意和类成员式的循环引用区分开
                           if (isDependent(beanName, dep)) {
                               throw new BeanCreationException(mbd.getResourceDescription(), beanName,
                                       "Circular depends-on relationship between '" + beanName + "' and '" + dep + "'");
                           }
                           registerDependentBean(dep, beanName);
                           try {
                            //先初始化被依赖项,再反递归回来
                               getBean(dep);
                           }
                           catch (NoSuchBeanDefinitionException ex) {
                               throw new BeanCreationException(mbd.getResourceDescription(), beanName,
                                       "'" + beanName + "' depends on missing bean '" + dep + "'", ex);
                           }
                       }
                   }

                   // Create bean instance
                  //如果是singleton的,就创建singleton实例
                   if (mbd.isSingleton()) {
                          //获取singleton源码,
                       sharedInstance = getSingleton(beanName, () -> {
                           try {
                               //创建bean的详情,创建bean的过程中会为为所有标记了被spring托管的类的field进行递归作doGetBean()的操作
                               return createBean(beanName, mbd, args);
                           }
                           catch (BeansException ex) {
                               // Explicitly remove instance from singleton cache: It might have been put there
                               // eagerly by the creation process, to allow for circular reference resolution.
                               // Also remove any beans that received a temporary reference to the bean.
                               destroySingleton(beanName);
                               throw ex;
                           }
                       });
                       bean = getObjectForBeanInstance(sharedInstance, name, beanName, mbd);
                   }
                  //如果是prototype的,创建prototype实例
                   else if (mbd.isPrototype()) {
                       // It's a prototype -> create a new instance.
                       Object prototypeInstance = null;
                       try {
                           beforePrototypeCreation(beanName);
                           prototypeInstance = createBean(beanName, mbd, args);
                       }
                       finally {
                           afterPrototypeCreation(beanName);
                       }
                       bean = getObjectForBeanInstance(prototypeInstance, name, beanName, mbd);
                   }
                   //如果不是singleton或者prototype的话,就委托给相应的实现类来处理
                   else {
                       String scopeName = mbd.getScope();
                       final Scope scope = this.scopes.get(scopeName);
                       if (scope == null) {
                           throw new IllegalStateException("No Scope registered for scope name '" + scopeName + "'");
                       }
                       try {
                           Object scopedInstance = scope.get(beanName, () -> {
                               beforePrototypeCreation(beanName);
                               try {
                                   return createBean(beanName, mbd, args);
                               }
                               finally {
                                   afterPrototypeCreation(beanName);
                               }
                           });
                           bean = getObjectForBeanInstance(scopedInstance, name, beanName, mbd);
                       }
                       catch (IllegalStateException ex) {
                           throw new BeanCreationException(beanName,
                                   "Scope '" + scopeName + "' is not active for the current thread; consider " +
                                   "defining a scoped proxy for this bean if you intend to refer to it from a singleton",
                                   ex);
                       }
                   }
               }
               catch (BeansException ex) {
                   cleanupAfterBeanCreationFailure(beanName);
                   throw ex;
               }
           }

           // Check if required type matches the type of the actual bean instance.
           // 最后再检查一下类型
           if (requiredType != null && !requiredType.isInstance(bean)) {
               try {
                   T convertedBean = getTypeConverter().convertIfNecessary(bean, requiredType);
                   if (convertedBean == null) {
                       throw new BeanNotOfRequiredTypeException(name, requiredType, bean.getClass());
                   }
                   return convertedBean;
               }
               catch (TypeMismatchException ex) {
                   if (logger.isDebugEnabled()) {
                       logger.debug("Failed to convert bean '" + name + "' to required type '" +
                               ClassUtils.getQualifiedName(requiredType) + "'", ex);
                   }
                   throw new BeanNotOfRequiredTypeException(name, requiredType, bean.getClass());
               }
           }
           return (T) bean;
       }

实例化bean的过程 doCreateBean

实例化bean的步骤主要有三个

createBeanInstance 实例化 -----> populateBean填充属性 --------> InitializeBean 初始化

在doGetBean()方法的调用过程中,在singleton作用域下spring会调用createBean()去实例化一个bean() createBean会组装好数据后,最终调用doCreateBean()方法实例化bean,具体代码如下

/**
     * Actually create the specified bean. Pre-creation processing has already happened
     * at this point, e.g. checking {@code postProcessBeforeInstantiation} callbacks.
     * <p>Differentiates between default bean instantiation, use of a
     * factory method, and autowiring a constructor.
     * @param beanName the name of the bean
     * @param mbd the merged bean definition for the bean
     * @param args explicit arguments to use for constructor or factory method invocation
     * @return a new instance of the bean
     * @throws BeanCreationException if the bean could not be created
     * @see #instantiateBean
     * @see #instantiateUsingFactoryMethod
     * @see #autowireConstructor
     */
    protected Object doCreateBean(final String beanName, final RootBeanDefinition mbd, final @Nullable Object[] args)
            throws BeanCreationException {

        // Instantiate the bean.
        // BeanWrapper为Bean的包装类,持有新创建的bean的引用
        BeanWrapper instanceWrapper = null;
        if (mbd.isSingleton()) {
            //如果是singleton作用域的话,则把想用name的bean从缓存中删掉
            instanceWrapper = this.factoryBeanInstanceCache.remove(beanName);
        }
        if (instanceWrapper == null) {
            //真正实例化bean在下面的方法完成,下文还有介绍
            instanceWrapper = createBeanInstance(beanName, mbd, args);
        }
        final Object bean = instanceWrapper.getWrappedInstance();
        Class<?> beanType = instanceWrapper.getWrappedClass();
        if (beanType != NullBean.class) {
            mbd.resolvedTargetType = beanType;
        }

        // Allow post-processors to modify the merged bean definition.
        synchronized (mbd.postProcessingLock) {
            if (!mbd.postProcessed) {
                try {
                    applyMergedBeanDefinitionPostProcessors(mbd, beanType, beanName);
                }
                catch (Throwable ex) {
                    throw new BeanCreationException(mbd.getResourceDescription(), beanName,
                            "Post-processing of merged bean definition failed", ex);
                }
                mbd.postProcessed = true;
            }
        }

        // Eagerly cache singletons to be able to resolve circular references
        // even when triggered by lifecycle interfaces like BeanFactoryAware.
        // 这里是为了解决循环依赖的,先把初步实例化的Bean实例的引用缓存起来,暴露出去
        boolean earlySingletonExposure = (mbd.isSingleton() && this.allowCircularReferences &&
                isSingletonCurrentlyInCreation(beanName));
        if (earlySingletonExposure) {
            if (logger.isDebugEnabled()) {
                logger.debug("Eagerly caching bean '" + beanName +
                        "' to allow for resolving potential circular references");
            }
            addSingletonFactory(beanName, () -> getEarlyBeanReference(beanName, mbd, bean));
        }

        // Initialize the bean instance.
        Object exposedObject = bean;
        try {
            // 填充新添加bean的属性,循环引用这里会调用
            populateBean(beanName, mbd, instanceWrapper);
                // 处理 InitializingBean 接口、BeanPostProcessor 接口等
                 // 这里就是处理 bean 初始化完成后的各种回调,调用顺序 调用BeanPostProcessor.postProcessBeforeInitialization() -> InitializingBean.afterPropertiesSet() ->
                // BeanPostProcessor.postProcessAfterInitialization()
            exposedObject = initializeBean(beanName, exposedObject, mbd);
        }
        catch (Throwable ex) {
            if (ex instanceof BeanCreationException && beanName.equals(((BeanCreationException) ex).getBeanName())) {
                throw (BeanCreationException) ex;
            }
            else {
                throw new BeanCreationException(
                        mbd.getResourceDescription(), beanName, "Initialization of bean failed", ex);
            }
        }

        //如果该beanName对象已经注册单例模式,则从单例中获取,并判断获取到的bean实例(B)与BeanWrapper中的bean实例(A)是同一个实例,如果是,则返回A或者B,如果不是,则递归找出它的依赖bean。
        if (earlySingletonExposure) {
            Object earlySingletonReference = getSingleton(beanName, false);
            // earlySingletonReference只有在检测到有循环依赖的情况下才会不为空
            if (earlySingletonReference != null) {
                if (exposedObject == bean) {
                    // 两个是同一个引用,bean初始化完成
                    exposedObject = earlySingletonReference;
                }   // 否则就递归查找依赖
                else if (!this.allowRawInjectionDespiteWrapping && hasDependentBean(beanName)) {
                    String[] dependentBeans = getDependentBeans(beanName);
                    Set<String> actualDependentBeans = new LinkedHashSet<>(dependentBeans.length);
                    for (String dependentBean : dependentBeans) {
                        if (!removeSingletonIfCreatedForTypeCheckOnly(dependentBean)) {
                            actualDependentBeans.add(dependentBean);
                        }
                    }
                    if (!actualDependentBeans.isEmpty()) {
                        throw new BeanCurrentlyInCreationException(beanName,
                                "Bean with name '" + beanName + "' has been injected into other beans [" +
                                StringUtils.collectionToCommaDelimitedString(actualDependentBeans) +
                                "] in its raw version as part of a circular reference, but has eventually been " +
                                "wrapped. This means that said other beans do not use the final version of the " +
                                "bean. This is often the result of over-eager type matching - consider using " +
                                "'getBeanNamesOfType' with the 'allowEagerInit' flag turned off, for example.");
                    }
                }
            }
        }

        // Register bean as disposable.
        // 编辑注册的bean为可使用状态
        try {
            registerDisposableBeanIfNecessary(beanName, bean, mbd);
        }
        catch (BeanDefinitionValidationException ex) {
            throw new BeanCreationException(
                    mbd.getResourceDescription(), beanName, "Invalid destruction signature", ex);
        }

        return exposedObject;
    }

spring解决循环引用问题

循环引用问题在spring中非常常见,即假设spring中A对象中含有标记了@Autowired的B对象的成员变量,B中同样含有标记了@Autowired的A对象的成员变量,称为循环引用。

循环引用分析

上文提到,spring 单例对象的创建主要分为三步

createBeanInstance 实例化 -----> populateBean填充属性 --------> InitializeBean 初始化

对于单例来说,在Spring容器整个生命周期内,有且只有一个对象,所以很容易想到这个对象应该存在Cache中,Spring为了解决单例的循环依赖问题,使用了三级缓存

代码在org.springframework.beans.factory.support.DefaultSingletonBeanRegistry中

/** Cache of singleton objects: bean name --> bean instance */
private final Map<String, Object> singletonObjects = new ConcurrentHashMap<String, Object>(256);

/** Cache of singleton factories: bean name --> ObjectFactory */
private final Map<String, ObjectFactory<?>> singletonFactories = new HashMap<String, ObjectFactory<?>>(16);

/** Cache of early singleton objects: bean name --> bean instance */
private final Map<String, Object> earlySingletonObjects = new HashMap<String, Object>(16);

/** Names of beans that are currently in creation */
    private final Set<String> singletonsCurrentlyInCreation =
            Collections.newSetFromMap(new ConcurrentHashMap<>(16)); //spring会将正在创建的bean的name放入该set

这三级缓存分别指:
singletonFactories : 单例对象工厂的cache
earlySingletonObjects :提前暴光的单例对象的Cache
singletonObjects:单例对象的cache

所以,在获取singleton bean的方法getSingleton源码如下

@Nullable
    protected Object getSingleton(String beanName, boolean allowEarlyReference) {
        Object singletonObject = this.singletonObjects.get(beanName); //从一级缓存中直接获取
        if (singletonObject == null && isSingletonCurrentlyInCreation(beanName)) { //如果缓存中没有并且bean正在被创建中
            synchronized (this.singletonObjects) {
                singletonObject = this.earlySingletonObjects.get(beanName); //从二级缓存earlySingletonObjects中获取,earlySingletonObjects表示可以提前暴露给context的bean,
//表名只进行了第一步操作,没有执行后续填充属性和初始化
                if (singletonObject == null && allowEarlyReference) { //如果还是没有并且允许从factory中获取对象的话
                    ObjectFactory<?> singletonFactory = this.singletonFactories.get(beanName);//从factotyMap中获取factory
                    if (singletonFactory != null) {
                        singletonObject = singletonFactory.getObject();   //从factory中获取对象
                        this.earlySingletonObjects.put(beanName, singletonObject);  //加入到二级缓存中
                        this.singletonFactories.remove(beanName);//从一级缓存中删除
                    }
                }
            }
        }
        return singletonObject;
    }

在依赖注入创建bean的过程中,spring通过把实例化好的bean以缓存的方式提前暴露给全局context的形式 在上面的代码中其实已经看到,这里再贴一次。

代码在org.springframework.beans.factory.support.AbstractAutowireCapableBeanFactory#doCreateBean中

        // Eagerly cache singletons to be able to resolve circular references
        // even when triggered by lifecycle interfaces like BeanFactoryAware.
        // 这里是为了解决循环依赖的,先把初步实例化的Bean实例的引用缓存起来,暴露出去
        boolean earlySingletonExposure = (mbd.isSingleton() && this.allowCircularReferences &&
                isSingletonCurrentlyInCreation(beanName)); //如果对象是singleton 并且允许循环引用并且bean是处于正在被创建状态,就执行下面的方法
        if (earlySingletonExposure) {
            if (logger.isDebugEnabled()) {
                logger.debug("Eagerly caching bean '" + beanName +
                        "' to allow for resolving potential circular references");
            }
            addSingletonFactory(beanName, () -> getEarlyBeanReference(beanName, mbd, bean)); //就EarlyBean引用添加到factory中
        }
protected void addSingletonFactory(String beanName, ObjectFactory<?> singletonFactory) {
    Assert.notNull(singletonFactory, "Singleton factory must not be null");
    synchronized (this.singletonObjects) { //上锁
        if (!this.singletonObjects.containsKey(beanName)) { //如果实例好的singleton bean中没有
            this.singletonFactories.put(beanName, singletonFactory);
            this.earlySingletonObjects.remove(beanName); //将bean从提前暴光的单例对象中删除
            this.registeredSingletons.add(beanName);
        }
    }
}

这段代码发生在createBeanInstance之后,也就是说单例对象此时已经被创建出来(调用了构造器)。这个对象已经被生产出来了,虽然还不完美(还没有进行初始化的第二步和第三步),但是已经能被人认出来了(根据对象引用能定位到堆中的对象),所以Spring此时将这个对象提前曝光出来让大家认识,让大家使用。

这样做有什么好处呢?让我们来分析一下“A的某个field或者setter依赖了B的实例对象,同时B的某个field或者setter依赖了A的实例对象”这种循环依赖的情况。A首先完成了初始化的第一步,并且将自己提前曝光到singletonFactories中,此时进行初始化的第二步,发现自己依赖对象B,此时就尝试去get(B),发现B还没有被create,所以走create流程,B在初始化第一步的时候发现自己依赖了对象A,于是尝试get(A),尝试一级缓存singletonObjects(肯定没有,因为A还没初始化完全),尝试二级缓存earlySingletonObjects(也没有),尝试三级缓存singletonFactories,由于A通过ObjectFactory将自己提前曝光了,所以B能够通过ObjectFactory.getObject拿到A对象(虽然A还没有初始化完全,但是总比没有好呀),B拿到A对象后顺利完成了初始化阶段1、2、3,完全初始化之后将自己放入到一级缓存singletonObjects中。此时返回A中,A此时能拿到B的对象顺利完成自己的初始化阶段2、3,最终A也完成了初始化,进去了一级缓存singletonObjects中,而且更加幸运的是,由于B拿到了A的对象引用,所以B现在hold住的A对象完成了初始化。

真正实例化bean的地方 createBeanInstance()

在上面的doCreateBean的方法中,调用了该方法来真正实例化bean

/**
     * Create a new instance for the specified bean, using an appropriate instantiation strategy:
     * factory method, constructor autowiring, or simple instantiation.
     * @param beanName the name of the bean
     * @param mbd the bean definition for the bean
     * @param args explicit arguments to use for constructor or factory method invocation
     * @return a BeanWrapper for the new instance
     * @see #obtainFromSupplier
     * @see #instantiateUsingFactoryMethod
     * @see #autowireConstructor
     * @see #instantiateBean
     */
    protected BeanWrapper createBeanInstance(String beanName, RootBeanDefinition mbd, @Nullable Object[] args) {
        // Make sure bean class is actually resolved at this point.
        //解析bean的class
        Class<?> beanClass = resolveBeanClass(mbd, beanName);
        //检查bean的权限
        if (beanClass != null && !Modifier.isPublic(beanClass.getModifiers()) && !mbd.isNonPublicAccessAllowed()) {
            throw new BeanCreationException(mbd.getResourceDescription(), beanName,
                    "Bean class isn't public, and non-public access not allowed: " + beanClass.getName());
        }

        Supplier<?> instanceSupplier = mbd.getInstanceSupplier();
        if (instanceSupplier != null) {
            return obtainFromSupplier(instanceSupplier, beanName);
        }
        // 如果工厂方法不为空,则是用工厂方法初始化
        if (mbd.getFactoryMethodName() != null)  {
            return instantiateUsingFactoryMethod(beanName, mbd, args);
        }

        // Shortcut when re-creating the same bean...
        boolean resolved = false;
        boolean autowireNecessary = false;
        if (args == null) {
            synchronized (mbd.constructorArgumentLock) {
                //如果有解析过的构造方法或者工厂方法,则标志resolve为true
                if (mbd.resolvedConstructorOrFactoryMethod != null) {
                    resolved = true;
                    autowireNecessary = mbd.constructorArgumentsResolved;
                }
            }
        }
        if (resolved) {
            if (autowireNecessary) {
                //构造方法自动注入,这里面又是依赖注入,最终还是会递归到doGetBean
                return autowireConstructor(beanName, mbd, null, null);
            }
            else {
                //否则直接instance
                return instantiateBean(beanName, mbd);
            }
        }

        // Candidate constructors for autowiring?
        //构造构造函数
        // 判断是否采用有参构造函数
        // 构造器自动装配
        Constructor<?>[] ctors = determineConstructorsFromBeanPostProcessors(beanClass, beanName);
        if (ctors != null || mbd.getResolvedAutowireMode() == AUTOWIRE_CONSTRUCTOR ||
                mbd.hasConstructorArgumentValues() || !ObjectUtils.isEmpty(args))  {
               //构造方法自动注入
            return autowireConstructor(beanName, mbd, ctors, args);
        }

        // 否则直接instance
        return instantiateBean(beanName, mbd);
    }

创建bean后的填充对象 populateBean()

因为是填充bean对象的所有field,即实例化bean的所有成员变量。所以采用@Autowired注解的引用会在这里进行依赖注入。下面来看源码

/**
     * Populate the bean instance in the given BeanWrapper with the property values
     * from the bean definition.
     * @param beanName the name of the bean
     * @param mbd the bean definition for the bean
     * @param bw the BeanWrapper with bean instance
     */
    protected void populateBean(String beanName, RootBeanDefinition mbd, @Nullable BeanWrapper bw) {
        if (bw == null) {
            if (mbd.hasPropertyValues()) {
                throw new BeanCreationException(
                        mbd.getResourceDescription(), beanName, "Cannot apply property values to null instance");
            }
            else {
                // Skip property population phase for null instance.
                return;
            }
        }

        // Give any InstantiationAwareBeanPostProcessors the opportunity to modify the
        // state of the bean before properties are set. This can be used, for example,
        // to support styles of field injection.

        boolean continueWithPropertyPopulation = true;
         // 这里看注解是一个扩展点
        // InstantiationAwareBeanPostProcessor 的实现类可以在这里对 bean 进行状态修改
        if (!mbd.isSynthetic() && hasInstantiationAwareBeanPostProcessors()) {
            for (BeanPostProcessor bp : getBeanPostProcessors()) {
                if (bp instanceof InstantiationAwareBeanPostProcessor) {
                    InstantiationAwareBeanPostProcessor ibp = (InstantiationAwareBeanPostProcessor) bp;
                    if (!ibp.postProcessAfterInstantiation(bw.getWrappedInstance(), beanName)) {
                        continueWithPropertyPopulation = false;
                        break;
                    }
                }
            }
        }

        if (!continueWithPropertyPopulation) {
            return;
        }

        PropertyValues pvs = (mbd.hasPropertyValues() ? mbd.getPropertyValues() : null);
        //如果模式为通过bean名称装配或者通过type装配,则进入
        if (mbd.getResolvedAutowireMode() == AUTOWIRE_BY_NAME || mbd.getResolvedAutowireMode() == AUTOWIRE_BY_TYPE) {
            MutablePropertyValues newPvs = new MutablePropertyValues(pvs);
            // Add property values based on autowire by name if applicable.
            if (mbd.getResolvedAutowireMode() == AUTOWIRE_BY_NAME) {
                //通过beanName装配
                autowireByName(beanName, mbd, bw, newPvs);
            }
            // Add property values based on autowire by type if applicable.
            if (mbd.getResolvedAutowireMode() == AUTOWIRE_BY_TYPE) {
                //通过type装配()
                autowireByType(beanName, mbd, bw, newPvs);
            }
            pvs = newPvs;
        }

        boolean hasInstAwareBpps = hasInstantiationAwareBeanPostProcessors();
        boolean needsDepCheck = (mbd.getDependencyCheck() != AbstractBeanDefinition.DEPENDENCY_CHECK_NONE);

        if (hasInstAwareBpps || needsDepCheck) {
            if (pvs == null) {
                pvs = mbd.getPropertyValues();
            }
            PropertyDescriptor[] filteredPds = filterPropertyDescriptorsForDependencyCheck(bw, mbd.allowCaching);
            if (hasInstAwareBpps) {
                for (BeanPostProcessor bp : getBeanPostProcessors()) {
                    if (bp instanceof InstantiationAwareBeanPostProcessor) {
                        InstantiationAwareBeanPostProcessor ibp = (InstantiationAwareBeanPostProcessor) bp;
                        // InstantiationAwareBeanPostProcessor.postProcessPropertyValues方法
                        // 代表能对属性值进行修改的能力
                        // 其中一个很有用实现类提一下,AutowiredAnnotationBeanPostProcessor
                        // 对采用@Autowired和@Value设值的就是这个BeanPostProcessor干的。
                        pvs = ibp.postProcessPropertyValues(pvs, filteredPds, bw.getWrappedInstance(), beanName);
                        if (pvs == null) {
                            return;
                        }
                    }
                }
            }
            if (needsDepCheck) {
                checkDependencies(beanName, mbd, filteredPds, pvs);
            }
        }

        if (pvs != null) {
            //最后把属性值
            applyPropertyValues(beanName, mbd, bw, pvs);
        }
    }

采用@Autowired 方式注入的具体实现

依赖注入最开始在doGetBean()方法中调用registerDependentBean,

spring 依赖注入 @Autowired 通过 org.springframework.beans.factory.annotation.AutowiredAnnotationBeanPostProcessor#postProcessPropertyValues

具体注入代码

@Override
        protected void inject(Object bean, @Nullable String beanName, @Nullable PropertyValues pvs) throws Throwable {
            Field field = (Field) this.member;
            Object value;
            if (this.cached) {
                value = resolvedCachedArgument(beanName, this.cachedFieldValue);
            }
            else {
                DependencyDescriptor desc = new DependencyDescriptor(field, this.required);
                desc.setContainingClass(bean.getClass());
                Set<String> autowiredBeanNames = new LinkedHashSet<>(1);
                Assert.state(beanFactory != null, "No BeanFactory available");
                TypeConverter typeConverter = beanFactory.getTypeConverter();
                try {
                    //拿到需要注入的对象 即field,这里,最终会重新调到doGetBean方法实现依赖注入
                    value = beanFactory.resolveDependency(desc, beanName, autowiredBeanNames, typeConverter);
                }
                catch (BeansException ex) {
                    throw new UnsatisfiedDependencyException(null, beanName, new InjectionPoint(field), ex);
                }
                synchronized (this) {
                    if (!this.cached) {
                        if (value != null || this.required) {
                            this.cachedFieldValue = desc;
                            registerDependentBeans(beanName, autowiredBeanNames);
                            if (autowiredBeanNames.size() == 1) {
                                String autowiredBeanName = autowiredBeanNames.iterator().next();
                                if (beanFactory.containsBean(autowiredBeanName) &&
                                        beanFactory.isTypeMatch(autowiredBeanName, field.getType())) {
                                    this.cachedFieldValue = new ShortcutDependencyDescriptor(
                                            desc, autowiredBeanName, field.getType());
                                }
                            }
                        }
                        else {
                            this.cachedFieldValue = null;
                        }
                        this.cached = true;
                    }
                }
            }
            if (value != null) {
                ReflectionUtils.makeAccessible(field);
                field.set(bean, value);
            }
        }
    }
